SATCOM tools
Satellite look angle calculator.
Find the azimuth, elevation and polarization skew from any site to any geostationary satellite, and see where the arc sits in your sky.
Reading the results
What each number means.
Azimuth & elevation
Azimuth is the compass direction to the satellite, measured clockwise from true north. Elevation is how far above the horizon to tilt the antenna. Below about 10° elevation, obstructions and rain fade become serious concerns.
Polarization skew
For linear polarization, the feed must be rotated so it lines up with the satellite’s signal. The skew grows the farther the satellite is east or west of your longitude, and the calculator shows which way to turn it.
Slant range
The straight-line distance from your antenna to the satellite. It sets the free-space path loss in a link budget, and it is longest for satellites low on the horizon.
Need the antenna size for your link? Try the antenna gain & G/T calculator, or have our engineers build a full link budget.
